Cadet Training Ship (CTS)
Displacement (Light / Full Load)
2187.5 ton / 1890,5 ton
Length Overall
89.59 m
Beam
14.18 m
Draught (Full Load)
Aft 3.54m / Fore 3.56m
Description

CTS (OPV class Cadet Training Ship) is indigenously designed to provide every aspect training such as combat management, navigation, weapon, engineer, diver trainings etc. to naval trainees on board. Thanks to its unique design details, it provides vast of capabilities for Cadet Training such as two separate full control bridge decks, 5 special individual classrooms (can be united easily to form a huge conference hall). In addition to its primary role, CTS can be deployed for offshore patrol duties as a secondary mission.

Propulsion System
2 x 5460 kW Diesel Engines
2 x CPP Propeller
Bow Thruster
Speed
Continuous: 18.0 knots
Maximum: 22.0 knots
Weapons
1 x 30 mm Gun with E/O Suit
2 x 12.7 mm Machine Guns
Electric Power
3 x 478 kW Diesel Generators
1 x 265 kW Emergency Generator
Navigation
2 x X-Band Radar
1 x S Band Radar
Ship Data Distribution System
GYRO System
Magnetic Compass
Electro Magnetic Log
Echo Sounder
DGPS
Wind Measurement and Indicator
AIS
ECDIS
CCTV
Ship Time System
Autopilot
Voyage Data Recorder
Communication
Visual and Audio Communication System
HF, V/UHF, VHF Military
SATCOM
SART-EPIRB
Ship Telephone System
CCTV
Complement
Officers: 11
Petty Officers: 22
Ratings: 27
Instructors: 8
Cadets: 76
Civilians: 6
Sensors
Electro Optical System
Helicopter
NH 90 or any 11 t helo
Emergency Generator
Power: 265 kW
